Panic bars—also called exit devices or crash bars—are essential safety features for commercial buildings, providing quick egress during emergencies. But not all panic bars are created equal. ANSI Grade 1 panic bars represent the highest quality standard, designed to withstand heavy use and meet strict safety requirements.
Choosing the right panic bar involves understanding key features that ensure reliability, durability, and compliance. Here's what you need to know before making your purchase.
ANSI (American National Standards Institute) grades panic bars on a scale of 1 to 3, with Grade 1 being the most robust. These devices must pass rigorous testing according to ANSI/BHMA A156.3 standards, including:
500,000 operational cycles (compared to 250,000 for Grade 2)
Impact resistance testing
Salt spray corrosion testing
Temperature cycling tests
An ANSI Grade 1 rating means the panic bar can handle high-traffic environments like hospitals, schools, stadiums, and office buildings where durability is non-negotiable.
Fire safety is paramount when selecting a panic bar. Look for devices that meet UL 10C and ULC-S104 standards, which test fire resistance for up to three hours. Fire-rated panic bars maintain their integrity during a fire, preventing smoke and flames from spreading while allowing safe evacuation.
If your building requires fire-rated doors, your panic bar must match or exceed the door's fire rating. Always verify that the device has proper UL listing to ensure compliance with local building codes.
The materials used in your panic bar directly impact its longevity and performance. Two primary options dominate the market:
Aluminum panic bars offer excellent corrosion resistance and a lightweight design. They're ideal for interior applications and moderate-traffic areas. Aluminum devices typically cost less while still providing ANSI Grade 1 performance.
Stainless steel panic bars deliver superior strength and weather resistance. They're the preferred choice for exterior doors, high-traffic entrances, or locations exposed to harsh environmental conditions. While more expensive, stainless steel devices offer exceptional durability and a professional appearance.
A quality panic bar consists of several integrated components working together. Understanding these parts helps you evaluate overall quality:
Push pad/touch bar: The horizontal bar that activates the mechanism when pressed
Latching mechanism: Connects to the door frame to secure the door when closed
Dogging feature: Allows the bar to be locked in a retracted position for high-traffic periods (when permitted by code)
Trim: The exterior hardware that complements the panic bar's function and appearance
Strike plate: The component mounted to the door frame that receives the latch
High-quality panic bars use precision-machined parts that fit together seamlessly, reducing wear and preventing mechanical failures.
Panic bars come in three main configurations, each suited to different door types:
Vertical rod devices use rods that extend into the door frame at both the top and bottom. They're excellent for double doors and provide secure multi-point locking.
Rim exit devices mount to the door's interior surface and operate a surface-mounted latch. They're easier to install and work well for single doors.
Mortise exit devices integrate with a mortise lock mechanism inside the door. They offer a clean appearance and work with existing mortise lock preparations.
Your door type and security requirements will determine which configuration works best for your application.
The outside of your door needs hardware that complements the panic bar while maintaining security. Trim options include:
Pull handles for easy door operation
Keyed cylinders for controlled access
Lever or knob trim that matches your building's aesthetic
Electrified options for access control integration
Select trim that balances accessibility with your security needs. Some applications may require passage trim (always unlocked), while others need keyed entry from the exterior.
Your panic bar must meet ADA (Americans with Disabilities Act) requirements. Key accessibility features include:
Maximum operating force of 15 pounds to unlatch
Activation with a closed fist (no twisting or grasping required)
Mounting height between 34 and 48 inches from the floor
Contrasting color or texture for visual identification
Proper accessibility ensures all building occupants can safely exit during an emergency.
Depending on your needs and local codes, you may want panic bars with additional locking capabilities:
Mechanical dogging allows the latch to be held in a retracted position, making the door function like a standard passage door. This feature is useful during business hours but must comply with fire code requirements.
Key-operated dogging requires a key to engage the dogging function, providing better control over when the feature is used.
Electrified options integrate with building access control systems, allowing remote locking and monitoring.
Never compromise on life safety—ensure any locking features comply with local fire and building codes.
Choose a manufacturer with proven expertise in ANSI-grade hardware. Look for companies that:
Maintain UL and ANSI certifications
Offer comprehensive warranties
Provide technical support and installation guidance
Use quality materials and precision manufacturing
Established manufacturers like Keyman Lock specialize in ANSI Grade 1 panic bars and can help you select the right device for your specific application.
Selecting an ANSI Grade 1 panic bar requires balancing safety, durability, aesthetics, and budget. Prioritize fire rating compliance, material quality, and proper certification. Consider your traffic volume, environmental conditions, and access control needs.
Work with knowledgeable suppliers who can guide you through the selection process and ensure you're choosing hardware that meets both code requirements and your operational needs. The right panic bar provides peace of mind, knowing your building occupants can safely exit in any emergency.
For expert guidance on ANSI Grade 1 panic bars and exit devices, contact Keyman Lock to discuss your specific requirements.
