Getting locked out can be frustrating, especially when you're dealing with a mortise lock. These heavy-duty locks are commonly found in commercial buildings, older homes, and apartment complexes. Unlike standard cylindrical locks, mortise locks are installed within a pocket cut into the door, making them more secure but also more complex to open.
Whether you've lost your key, the lock is malfunctioning, or you're simply curious about how these mechanisms work, understanding the proper techniques can save you time and money. This guide will walk you through several methods to open a mortise lock safely and legally.
Before we begin, it's important to note that these techniques should only be used on locks you own or have explicit permission to open. Attempting to open someone else's lock without permission is illegal and could result in serious consequences.
A mortise lock consists of several key components that work together to secure your door. The lock body sits inside a rectangular pocket (called a mortise) cut into the door's edge. This body contains the locking mechanism, springs, and cylinders.
The exterior trim plate covers the lock body and houses the keyhole, handle, and any additional hardware. Inside, you'll find the deadbolt, latch bolt, and various pins and springs that control the locking mechanism.
Understanding these components helps you choose the most appropriate opening method for your situation.
This technique works well for basic mortise locks without complex security features. You'll need a small flathead screwdriver and a straightened paperclip.
Start by inserting the screwdriver into the keyhole and applying gentle turning pressure in the direction you would normally turn a key. While maintaining this pressure, use the paperclip to manipulate the pins inside the lock cylinder.
Insert the paperclip above the screwdriver and gently push up on each pin while continuing to apply turning pressure with the screwdriver. You should feel each pin "set" as it reaches the correct position. Once all pins are set, the lock should turn and open.
This method requires patience and practice. Don't apply excessive force, as this could damage the lock mechanism or break your tools inside the keyhole.
The credit card method works primarily on mortise locks with spring-loaded latch bolts. This technique won't work on deadbolts or locks with anti-slip features.
Choose an old credit card or similar flexible plastic card that you don't mind potentially damaging. Slide the card between the door and the frame, positioning it above the latch bolt mechanism.
Angle the card toward the latch and apply downward pressure while pushing the card further into the gap. The goal is to push the latch bolt back into the door while simultaneously pushing or pulling the door open.
This method works best on doors that swing away from you and have sufficient gap between the door and frame.
Professional lock picking tools provide the most reliable method for opening mortise locks without causing damage. You'll need a tension wrench and several pick tools of different shapes.
Insert the tension wrench into the bottom of the keyhole and apply light turning pressure. Using your pick tool, locate and manipulate each pin in the lock cylinder. Start with the pins furthest from the opening and work your way forward.
As you lift each pin to the correct height, you should feel it "click" into place. The tension wrench will turn slightly when each pin sets correctly. Continue this process until all pins are set and the lock turns freely.
Quality lock picking requires significant practice to master. Consider taking a locksmithing course if you plan to use this skill regularly.
Drilling should be considered a last resort, as it permanently damages the lock and requires replacement afterward. This method is most appropriate when other techniques have failed and you need immediate access.
Use a drill bit slightly smaller than the keyhole diameter and drill directly into the shear line where the pins meet the cylinder. This destroys the pins and allows the cylinder to turn freely.
Start drilling slowly to avoid overheating the bit or creating metal shavings that could jam the mechanism further. Once you've drilled through the pin line, use a screwdriver to turn the cylinder and open the lock.
After drilling, you'll need to replace the entire lock cylinder or the complete mortise lock assembly, depending on the extent of the damage.
Sometimes the most efficient approach is removing the entire mortise lock from the door. This method requires basic tools and mechanical knowledge but avoids damaging the lock mechanism itself.
Start by removing the trim plate screws on both sides of the door. These screws typically hold the exterior hardware in place. Once removed, you should be able to pull the trim plates away from the door.
Next, locate and remove the screws holding the lock body within the mortise. These are usually found on the door's edge. With all screws removed, the lock body should slide out of the mortise, allowing you to open the door.
This method works well when you need to replace or repair the lock anyway, as it preserves most components for reuse or professional servicing.
Never attempt to open locks that don't belong to you or without explicit permission from the property owner. Lock manipulation techniques should only be used in legitimate situations such as lockouts from your own property.
Always wear safety glasses when drilling locks to protect your eyes from metal shavings. Work in well-ventilated areas and take frequent breaks to avoid overheating tools or materials.
Consider calling a professional locksmith for complex situations or high-security locks. Professional services often cost less than replacing damaged locks and provide guaranteed results.
Certain situations warrant professional assistance rather than DIY approaches. High-security mortise locks often include anti-tampering features that make amateur opening attempts ineffective or destructive.
If you're dealing with electronic or smart mortise locks, professional help prevents accidental damage to expensive components. Similarly, antique or historically significant locks should only be handled by experienced professionals who can preserve their value and functionality.
Time constraints may also necessitate professional help. A skilled locksmith can typically open most mortise locks within minutes, while DIY attempts might take hours without guaranteed success.
Regular maintenance prevents many lockout situations and extends your lock's lifespan. Lubricate the mechanism annually using graphite powder or specialized lock lubricant. Avoid oil-based lubricants that attract dirt and debris.
Check that all screws remain tight and that the lock operates smoothly. Address minor issues promptly before they become major problems requiring emergency opening techniques.
Consider having your locks professionally serviced every few years, especially in high-use commercial applications where reliability is crucial.
Opening a mortise lock doesn't have to be an insurmountable challenge. With the right knowledge, tools, and techniques, you can regain access to your property safely and efficiently. Remember that practice makes perfect—consider practicing these techniques on old locks before you need them in an emergency.
Whether you choose lock picking, mechanical manipulation, or professional assistance depends on your skill level, available tools, and the specific lock you're dealing with. Always prioritize safety and legality over speed, and don't hesitate to seek professional help when situations exceed your comfort zone.
