Choosing the right commercial door lock depends on your door type, traffic volume, security requirements, and budget. The three most common commercial door lock types are mortise locks, cylindrical locks, and exit devices (panic bars)—each suited to different applications and performance demands.
This guide compares all three across key decision factors and provides a practical selection framework for facility managers, architects, contractors, and procurement teams.
Table of Contents
Commercial door locks fall into three primary categories:
Mortise locks – High-security locks installed within a pocket (mortise) cut into the door edge. Preferred for heavy-duty commercial applications.
Cylindrical locks – Bored into the door face and edge, easier to install, and suited for moderate-traffic environments.
Exit devices (panic hardware) – Mounted across the door's push surface, designed for emergency egress and required by code on many commercial exit doors.
Each type serves a distinct purpose. Understanding the differences between mortise and cylindrical locks—and when an exit device is required instead—is essential before specifying hardware for any commercial project.
A mortise lock is installed inside the door body; a cylindrical lock is bored through the door face. This fundamental difference in installation method drives most of the performance and cost trade-offs between the two types.
Installation: Requires a deep rectangular pocket routed into the door edge. More labor-intensive to install.
Security: Higher intrinsic security due to a multi-point locking mechanism housed inside the door. Resistant to forced entry and kick-in attacks.
Durability: Engineered for high-cycle applications. ANSI Grade 1 mortise locks (such as Keyman's M7 Series) are rated for 250,000+ cycles and comply with ANSI/BHMA A156.13 and UL 10C fire-rating standards.
Cost: Higher upfront cost for both hardware and installation labor.
Best for: Office buildings, hospitals, hotels, schools, and any facility requiring consistent, high-security performance on heavily used doors.
Installation: Requires two standard bored holes—faster and less costly to install.
Security: Adequate for low-to-medium security applications; generally ANSI Grade 2 or 3.
Durability: Lower cycle ratings; more appropriate for interior or light-traffic doors.
Cost: Lower hardware and installation cost.
Best for: Interior office doors, storage rooms, and light-traffic commercial spaces where budget and ease of installation are priorities.
Decision rule: Mortise locks are better suited for exterior entry doors, high-traffic corridors, and security-sensitive areas. Cylindrical locks work best when installation simplicity and cost efficiency matter more than long-term durability.
Factor | Mortise Lock | Cylindrical Lock | Exit Device |
|---|---|---|---|
Installation | Complex (pocket cut required) | Simple (two bored holes) | Surface-mounted to door |
Security Level | High (ANSI Grade 1) | Moderate (Grade 2–3) | Egress-focused; pairs with trim |
Durability | 250,000+ cycles | 100,000–150,000 cycles | 250,000+ cycles (Grade 1) |
Fire Rating | Available (UL 10C, 3-hour) | Limited options | Available (UL 10C, 3-hour) |
Upfront Cost | Higher | Lower | Moderate–Higher |
Code Compliance | Broad commercial use | Limited to interior/light use | Required for most exit doors |
Typical Applications | Offices, hospitals, hotels | Interior doors, storerooms | Schools, public buildings, factories |
Exit devices (panic bars) are legally required by building codes on most commercial exit doors that serve 50 or more occupants. They allow rapid egress under pressure—without requiring users to turn a handle or operate a key—making them essential for life-safety compliance.
Key standards governing exit devices include:
ANSI/BHMA A156.3 – Performance standard for exit devices
UL 305 – Panic hardware listing
UL 10C / CAN/ULC-S104 – Fire-rated door assembly (up to 3-hour rating)
Keyman's UL/ANSI-listed exit device range includes:
X8 Aluminum Fire Rated Panic Exit Device – Lightweight, fire-rated 3 hours, suits high-volume exit doors
X9 Stainless Steel Exit Device – Heavy-duty corrosion-resistant option for demanding environments
X6 Medium Duty Narrow Exit Device – Designed for narrow stile doors
EN1125 Panic Exit Device – European standard compliance for international projects
Use the following criteria to guide your selection:
Wood or hollow metal door, standard thickness: Cylindrical lock may suffice for interior use.
Steel or solid wood door, exterior/entry: Mortise lock recommended.
Fire-rated door assembly: Verify UL listing compatibility for both lock and door.
High-traffic (100+ operations/day): Choose ANSI Grade 1 mortise lock or exit device.
Low-to-medium traffic (interior offices, closets): Cylindrical lock acceptable.
Maximum security (entry, server rooms, pharmacies): ANSI Grade 1 mortise lock with deadbolt.
Moderate security (interior zones): Grade 2 cylindrical lock.
Egress-only (emergency exits, stairwells): Exit device with outside trim.
Check local building codes for occupancy loads and egress requirements.
Confirm whether a UL-listed fire-rated assembly is mandated.
For European markets, verify CE/EN compliance (e.g., EN 12209 for mortise locks, EN 1125 for panic devices).
Lower budget, interior application: Cylindrical lock.
Medium-to-high budget, long-term durability required: Mortise lock or exit device.
Total cost of ownership consideration: ANSI Grade 1 hardware typically reduces replacement frequency and long-term maintenance costs.
Building Type | Recommended Lock Type | Keyman Product Reference |
|---|---|---|
Office Buildings | ANSI Grade 1 Mortise Lock | |
Hospitals & Healthcare | Mortise Lock (electrified optional) | |
Hotels | Motorized Mortise Lock (access control) | |
Schools | Exit Device + Mortise or Cylindrical Lock | |
Industrial Facilities | Stainless Steel Exit Device | |
Public Buildings (EU) | EN1125 Panic Exit Device |
Keyman Lock is an ANSI/UL-certified commercial hardware manufacturer with 20+ years of experience, supplying Grade 1 mortise locks, exit devices, and related hardware to global markets. All products are manufactured to ANSI/BHMA, UL, and CE EN standards.
Product Category | Series | Standard |
|---|---|---|
ANSI Grade 1 Mortise Lock | M7 Series | ANSI/BHMA A156.13, UL 10C (3-hour) |
Exit Device (Aluminum) | X8 Series | ANSI/BHMA A156.3, UL 305, UL 10C |
Exit Device (Stainless Steel) | X9 Series | ANSI/BHMA A156.3, UL 305, UL 10C |
Exit Device (Narrow, Medium Duty) | X6 Series | ANSI/BHMA A156.3 |
EN Euro Mortise Lock | M5 Series | EN 12209 Grade 3, EN 1634-1 (4⅓-hour) |
Electrified Mortise Lock | Solenoid / Motor | ANSI Grade 1, access control compatible |
Panic Exit Device (EU) | EN1125 Series | EN 1125, CE Marked |
Browse the full Keyman product range →
Q: What is the most secure type of commercial door lock?
An ANSI Grade 1 mortise lock offers the highest security rating for commercial doors. Keyman's M7 Series, certified to ANSI/BHMA A156.13 and UL 10C, provides 3-hour fire resistance and is designed to withstand 250,000+ use cycles.
Q: Do I need an exit device on every commercial door?
Not every door requires an exit device, but most jurisdictions require panic hardware on any door serving an assembly or occupancy of 50 or more people. Always consult local building codes and fire codes before specifying hardware.
Q: Can a mortise lock be used on a fire-rated door?
Yes. Fire-rated mortise locks—such as those certified to UL 10C and CAN/ULC-S104—are specifically designed and tested for fire door assemblies. Always match the lock's fire rating to the door assembly's rating (e.g., 3-hour door requires a 3-hour rated lock).
Q: What is the difference between a solenoid and motor mortise lock?
A solenoid mortise lock uses an electromagnetic coil to control the latch or bolt electrically—typically for fail-secure or fail-safe access control applications. A motor mortise lock uses a small electric motor for quieter, more controlled operation and is commonly used in hotel key card systems and smart access platforms.
Q: How do I know if a cylindrical lock is ANSI Grade 1?
ANSI Grade 1 is the highest performance classification under ANSI/BHMA A156.2. To confirm a product's grade, look for the ANSI/BHMA certification mark and test report. Most Grade 1 cylindrical locks are rated for 250,000 cycles and meet additional security and strength criteria. Mortise locks, however, are generally preferred over cylindrical locks for Grade 1 commercial applications.
