Electrified Exit Device Applications
An electrified exit device for commercial security doors combines panic hardware with an electric actuator - such as electric latch retraction (ELR) or electrified trimso a door can be monitored and controlled by an access control system while always remaining free to open from the inside for emergency egress. This makes electrified exit devices a core building block for facilities that need both life-safety compliance and perimeter security, from office towers to schools and healthcare campuses.
What Is an Electrified Exit Device for Commercial Security Doors?
An electrified exit device is a push-bar or crossbar panic hardware unit fitted with an electric actuator that allows the latch to be retracted or monitored remotely, integrating with card readers, access control panels, or building automation systems. Unlike a purely mechanical panic bar, an electric exit device lets security staff or software manage entry from the secure side, without ever restricting free egress from the inside a requirement of fire and life-safety codes.
Keyman's x800 (Aluminum) and X900 (Stainless Steel) Series are built around this principle. Both lines are UL-listed and certified to ANS/BHMAA156.3 Grade 1, UL 305 FVSR (Panic Hardware), and UL 10C/ULC-S104 for up to 3-hour fire-rated door assemblies- meeting the specification requirements common in offices,schools, banks, and assisted living facilities.
Quiet Electric Latch Retraction for Exit Devices
Electric Latch Retraction (ELR) uses a motorized or solenoid mechanism inside the push bar to pullthe latchbolt back electronically, enabling push-pull operation or remote unlatching from an access control panel. Because ELR mechanisms operate the latch directly, a well-engineered device minimizes the mechanical noise and vibration that can disrupt sensitive environments like healthcare corridors, classrooms, or open-plan offices.
Keyman pairs ELR functionality with a reduced-projection push bar design, which not only lowers catch hazards in high-traffic corridors but also contributes to smoother, quieter operation during both manual and electric release.
How Electrified Exit Devices Support REX and Egress Security
Request-to-Exit (REX) is the industry term for the signal an access control system receives whenever a door is used for legitimate egress - typically triggered by motion sensors, exit push buttons, or the exit device itself. Electrified exit devices are frequently wired to generate a REX signal so the access control panel can distinguish between an authorized exit and an unauthorized door-forced or door-held-open alarm, without ever compromising the mechanical freedom to exit.
This REX integration is what allows electrified panic hardware to serve two roles at once: guaranteeing code-compliant emergency egress from the inside, and giving facility managers visibility and control over entry from the outside.
