If your door has a bulb-shaped cylinder hole secured by one screw from the faceplate edge, it uses the Euro Profile standard. If the cylinder is a round, threaded body that screws directly into the lock case, it uses the ANSI standard. For buyers sourcing from Keyman, this distinction determines everything: the M5 Series Euro mortise locks pair with EN 1303 cylinders, while the M7 Series ANSI mortise locks use ANSI mortise cylinders. The two are not interchangeable without modifying the door or lock body.

The Shape Difference: Bulb Profile vs. Round Threaded Body

The euro profile cylinder lock—sometimes called a "profile cylinder" or "euro cylinder"—has a distinctive cross-section often described as a lightbulb or keyhole shape. This profile slides into a matching cutout in the mortise lock case and is the dominant format across Europe, the Middle East, and much of Southeast Asia. Understanding euro cylinder lock types begins with this profile: the bulb-shaped body is the defining feature that separates it from any ANSI-format cylinder, regardless of whether the cylinder is a double, half, or thumbturn variant.

ANSI mortise cylinders, by contrast, are cylindrical in form with a threaded exterior body. They screw directly into the lock case rather than sliding into a profile cutout. This design is the commercial standard in North America and is governed by ANSI/BHMA A156.13 for mortise locks.

The practical consequence is immediate: a Euro Profile cylinder cannot be forced into an ANSI lock case, and vice versa. The shapes are mechanically incompatible.

Installation Logic: One Screw vs. Threaded Insertion

Euro Profile installation is remarkably simple. The cylinder slides through the door and into the lock case, then a single fixing screw—accessed from the faceplate edge of the door—passes through the lock case and engages the cylinder body to secure it. This design makes cylinder replacement fast, but it also means the security of the cylinder depends partly on the strength of that single fixing point and the cylinder's resistance to snapping.

ANSI mortise cylinder installation uses a different principle. The threaded cylinder body screws into the lock case itself, and the cylinder is typically retained by the lock case mechanism and the door's escutcheon or rose. The cylinder's cam at the rear engages the lock mechanism to throw or retract the bolt. Length and cam configuration must match the lock case for proper operation. When specifying a mortise cylinder lock set, buyers must confirm that the cylinder, cam, and lock case are all matched to the same standard—a Euro Profile cylinder and an ANSI mortise lock case cannot be combined into a functional set.

Measurement Systems: Split Length vs. ANSI Dimensions

Getting the size right is where many procurement errors occur, because the two standards measure differently.

Euro Profile cylinders use a split length system. The critical measurement is from the center of the fixing screw hole to each end of the cylinder. For example, a "35/35" cylinder measures 35mm from the screw center to the interior end and 35mm to the exterior end, for a total length of 70mm. Asymmetric doors—common when the exterior side has a thicker panel or decorative trim—require asymmetric split lengths such as 30/40 or 35/45. The total length alone is insufficient; the split must match the door thickness on each side. These euro cylinder dimensions are the single most common source of ordering errors, because a cylinder that is correct in total length but wrong in split will not sit flush on both sides of the door.

ANSI mortise cylinders are typically specified by overall length and cam type. The threaded body diameter is standardized, but lengths vary, commonly in increments that correspond to door thickness plus escutcheon. The cam—the flat tail or shaped actuator at the rear—must match the lock case's slot or hub. A cylinder of the correct length but wrong cam will not operate the lock properly. This is why a mortise cylinder lock set is best specified as a matched combination of cylinder, cam, and lock case rather than as separate components.

EN 1303 Certification: What the Grades Actually Mean

EN 1303 is the European standard for cylinders and their keys. It does not use a single "Grade 1 to 6" scale in the way some buyers assume. Instead, the standard establishes multiple independent classifications: durability grades, mechanical coding grades, fire grades, corrosion resistance grades, and—critically for security—grades of key-related security based on design requirements and attack resistance.

Keyman's EN 1303 cylinders are tested to this standard, with features including anti-snap, anti-pick, anti-bump, and anti-drill protection in the M5-compatible line. When comparing EN 1303 claims between suppliers, buyers should ask for the specific grade or classification being claimed—durability cycles, attack resistance level, and whether fire door suitability is separately certified—rather than accepting a generic "EN 1303 certified" statement.

A practical benchmark: Keyman's EN 1303 double Euro Profile cylinder is tested for durability and security, and the 70mm (35/35) size is among the most common for standard European and UK doors. For fire-rated applications, a standard EN 1303 cylinder is not automatically sufficient; the cylinder must be tested as part of the fire door assembly, often with additional certification such as EN 1634-1.

Keyman Product Mapping: M5 Euro vs. M7 ANSI

Keyman manufactures both standards, which means buyers can source the correct cylinder and lock case from one supplier without mixing incompatible components.

For Euro Profile projects: The M5 Series CE EN Euro Mortice Lock is rated to EN 12209 Grade 3 and EN 1634-1 fire-rated for 4-1/3 hours, according to the product listing on Keyman's site. It accepts EN 1303 euro profile cylinder lock products, including Keyman's double and half cylinders in 45mm, 70mm, and other common split lengths. This is the appropriate specification for European residential and light commercial doors, as well as Middle East and Southeast Asian projects specified to EN standards.

For ANSI projects: The M7 Series UL ANSI Grade 1 Mortise Lock conforms to ANSI/BHMA A156.13 and carries UL 10C and CAN/ULC-S104 3-hour fire ratings. It accepts ANSI mortise cylinders with the correct length and cam for the lock case. When a project requires a complete mortise cylinder lock set, the M7 Series lock case should be paired with the matching ANSI cylinder and cam configuration. This is the North American commercial standard and is suitable for projects where UL listing and ANSI Grade 1 performance are required.

A buyer specifying a door hardware package should confirm the cylinder standard at the same time as the lock case standard. Keyman's existing article on cylinder interchangeability notes that even within the correct profile, dimensions must match; across profiles, no adaptation is safe or reliable. The M5 and M7 lines exist precisely to serve these two distinct markets without compromise.

Quick Decision Guide

For procurement teams, the simplest rule is this: match the cylinder standard to the lock case standard, and match the dimensions to the specific door preparation. Keyman's dual product lines allow sourcing both configurations from one manufacturer, but the two should never be assumed interchangeable in the field. If you are unsure which standard your project requires, the door's existing preparation—or the architect's specification—will indicate whether the cylinder cutout is a bulb profile or a threaded ANSI mortise.
