An offset pull handle is designed with a bent or angled profile that creates clearance between the handle and the door surface, allowing it to be mounted alongside a lock cylinder, knob, or other hardware without obstruction. A straight pull handle runs parallel to the door face in a simple, linear form — offering a clean aesthetic but no built-in clearance for co-located hardware.
Choosing the wrong type can result in a hardware conflict, a failed ADA inspection, or a costly reinstallation. This guide breaks down both commercial door pull types — their geometry, best-use applications, ADA compliance implications, and installation dimensions — so procurement managers and architects can make the right call the first time.
An offset pull handle is a door pull that incorporates one or more bends in its shank, shifting the grip portion away from the door surface by a set distance — typically 2.5 inches (63 mm) or more. This "offset" creates physical clearance between the grip and the door face.
Why does that clearance matter? When a mortise lock cylinder, thumbturn, or knob is installed at or near the same location on the door stile, a straight handle would sit flush against those components, making the lock difficult or impossible to operate. The offset profile solves this problem by ensuring the user's hand can comfortably reach and turn the cylinder even with the pull handle in place.
Typical applications for offset pull handles include:
Commercial and institutional doors fitted with mortise lock cylinders
Doors where the pull handle and lock trim occupy the same stile position
High-traffic entryways where both pulling and locking functions must remain accessible
Doors requiring ADA-compliant hardware configurations (see below)
Keyman Lock's pull handle range includes models such as the L37 and MH Handle series, both of which are available with detailed wire draft dimensions to assist with precise installation planning.
A straight pull handle is a linear bar or rod mounted parallel to the door surface via two end brackets. There is no angular offset — the grip sits at a fixed, uniform distance from the door, determined only by the projection of the mounting roses or brackets.
Straight pull handles excel in applications where the pull handle is the primary or sole hardware element on that face of the door. They offer a sleeker, more minimal appearance and are often specified for:
Glass storefront doors and all-glass entrances
Interior lobby doors where no lock cylinder is present on the pull side
Doors with concealed or flush-mounted locking mechanisms
Aesthetic-driven projects where a clean, uninterrupted line is the design priority
The key trade-off: Straight pull handles are better suited for doors where the locking hardware is located separately or on the opposite face, while offset pull handles work best when both the pull and the lock cylinder must share the same stile.
Feature | Offset Pull Handle | Straight Pull Handle |
|---|---|---|
Profile geometry | Angled / bent shank | Linear / straight shank |
Clearance from door face | Greater (accommodates co-located hardware) | Fixed by bracket projection only |
Best for | Doors with lock cylinder on same stile | Doors with no co-located lock trim |
ADA suitability | Often preferred for operable hardware compliance | Suitable when grip clearance meets code |
Aesthetic | Functional; traditional commercial look | Minimal; modern or architectural look |
Common applications | Office, institutional, high-security commercial | Glass storefronts, interior lobbies |
ADA-compliant pull handles must meet the requirements set out in the ADA Standards for Accessible Design, which reference the technical criteria in ICC/ANSI A117.1.
The core requirements for accessible door hardware include:
Operable with one hand without tight grasping, pinching, or twisting of the wrist
Activation force no greater than 5 lbf (22.2 N)
Mounting height between 34 inches (865 mm) and 48 inches (1220 mm) above the finished floor
Grip clearance: Hardware must allow a closed fist to pass around or alongside it
Offset pull handles frequently appear in ADA-compliant specifications because their geometry allows the user's hand to clear surrounding hardware — particularly lock cylinders — without obstruction. A straight pull handle can also be ADA compliant, provided there is no adjacent hardware restricting grip access and the mounting height falls within the required range.
Important note for specifiers: ADA compliance is determined by the full hardware assembly and door configuration, not by the handle type alone. Always verify that the combined projection, mounting height, and activation force of the complete door hardware package meets applicable code requirements before finalizing a specification.
Incorrect dimensional planning is one of the most common causes of field returns and hardware conflicts in commercial door projects. Before specifying either handle type, confirm the following measurements:
For offset pull handles:
Overall length of the handle bar
Backset distance — the horizontal distance from the edge of the door to the center of the lock cylinder
Offset projection — the distance the grip is shifted away from the door face (must clear the cylinder or knob)
Fixing centers — the distance between the two mounting points (rose to rose)
Grip diameter — must comply with ADA grip requirements if accessibility is required
For straight pull handles:
Overall length and grip length
Rose/bracket projection — determines clearance from the door face
Fixing centers
Door thickness — relevant for through-bolt installations
Keyman Lock provides detailed wire draft size documents and panel dimension line drafts for its MH Handle and L37 Handle series, available for download from the pull handle product page. These drawings allow architects and contractors to verify dimensional compatibility before ordering.
Use the following decision framework to select the appropriate pull handle for your project:
Choose an offset pull handle if: The lock cylinder, thumbturn, or knob is located on the same door stile as the pull handle, or if you need to ensure hand clearance around co-located hardware on a busy commercial or institutional door.
Choose a straight pull handle if: The pull handle is the only hardware element on that face of the door, the locking mechanism is concealed or located on the push side, or the project prioritizes a clean, architectural aesthetic over functional clearance.
For ADA-sensitive projects: Consult dimensional drawings and verify that both the grip clearance and mounting height comply with ANSI A117.1 before specifying either type.
Q: Can an offset pull handle be used on a glass door?
A: Yes, offset pull handles can be installed on glass doors, provided the door glass is drilled or fitted with appropriate mounting hardware. However, straight pull handles are more commonly specified for glass storefronts due to their cleaner aesthetic and simpler through-bolt installation.
Q: What is the standard offset dimension for a commercial offset pull handle?
A: There is no single universal standard, but commercial offset pull handles typically provide a clearance projection of 2.5 to 3 inches (63–76 mm) from the door face. The required offset depends on the diameter and projection of the co-located lock cylinder or knob. Always cross-reference the handle's dimensional drawing with the lock cylinder specification.
Q: Are offset pull handles more expensive than straight pull handles?
A: Offset pull handles typically carry a modest price premium over comparable straight pull handles due to their more complex geometry and manufacturing process. However, the cost difference is generally minor compared to the expense of a hardware conflict discovered during installation.
Q: How do I know if my pull handle meets ADA requirements?
A: Verify that the handle can be operated with one hand without grasping, pinching, or twisting; that the activation force does not exceed 5 lbf; and that the mounting height falls between 34 and 48 inches above the finished floor. For a complete assessment, review the full hardware assembly against ICC/ANSI A117.1.
