| Heavy Duty Lever Trim | |||
| 5D/5E | 02Function | 03Function | |
 |  |  | |
| Function | Dummy trim | Night latch | |
| Function Description | Entrance by trim when actuating bar is dogged down. | Entrance by trim when latchbolt is retracted by key(lever rigid) | |
| Product Code | X98025D01/X98025E01 | X98035D01/X98035E01 | |
| Escutcheon Plate Size | 23/4"x103/4"×27/32" | 23/4"x103/4"×27/32" | |
| (70x260x24mm) | (70x260x24mm) | ||
| Post Center to Center | |||
| Projection | |||
| ANSI Function | 2 | 3 | |
| Cylinder Type | — | ANSI Mortise Cylinder | |
| Handing | Handed/Reversible | ||
| 5D/5E | 08Function | 09Function | 14Function |
|  |  |  |
| Function | Classroom | Storeroom（Lever Active） | Passage |
| Function Description | Entrance by lever. Key locks or unlocks lever | Entrance by lever only when released by key. Key removable only when locked. | Entrance by trim when latchbolt is retracted by lever.Lever always active,no cylinder. |
| Product Code | X98085D01/X98085E01 | X98085D01/X98085E01 | X98145D01/X98145E01 |
| Escutcheon Plate Size | 23/4"x103/4"×27/32" | 23/4"x103/4"×27/32" | 23/4"x103/4"×27/32" |
| (70x260x24mm) | (70x260x24mm) | (70x260x24mm) | |
| Post Center to Center | |||
| Projection | |||
| ANSI Function | 8 | 9 | 14 |
| Cylinder Type | ANSI Mortise Cylinder | ANSI Mortise Cylinder | |
| Handing | Handed/Reversible | Handed/Reversible | Handed/Reversible |
| A wide selection of finishes are available to match with your door and other hardware. | |||
| Color | Description | ANSI/BHMA | US |
 | Satin Brass | 606 | SB |
 | Polished Chrome | 625 | CP |
 | Satin Chrome | 626 | SC |
 | Satin Stainless Steel | 630 | SS |
 Mortise Cylinder |  SFIC Cylinder |
| lllustration | Face | Length | |||||
| (29mm) | (32mm) | (35mm) | (38mm) | (41mm) | (45mm) | ||
 | Full-face Standard | FC729A | FC732A | FC735A | FC738A | FC741A | FC745A |
 | Full-face l/C Core | N/A | FCC32G | FCC35G | FCC38G | N/A | N/A |
| FC2-0003 Lock Head Puller N | FC2-0004 Lock Head Puller R | M700-062 Lock Head Puller H |
 |  |  |
 |  |  |
| M700-065 Lock Head Puller A | M700-093Lock Head Puller C | M700-102 Lock Head Puller D |
 |  |  |
 |  |  |
| L0100 | L0300 | L0400 | L0600 |
 |  |  |  |
 |  |  |  |
| L0800 | L0900 | L1500 | L1900 |
 |  |  |  |
| L2000 | L2100 | L3300 | L3700 |
 |  |  |  |
| L3800 | |||
 |
